MELSEC-A Series PLC
MELSEC-A SERIES PLC :-
| CPU | |
| A1SHCPU | BUILT IN 8KSTEPS RAM, MAX. I/O |
| A2SHCPU | BUILT IN 14KSTEPS RAM, MAX. I/O |
| A2SHCPU-S1 | CPU, BUILT IN 14KSTEPS RAM, MAX. I/O 1024 |
| A2ASCPU | CPU, BUILT IN 14KSTEPS RAM, MAX. I/O 512, 0.2us/STEP |
| A2ASCPU-S1 | CPU, BUILT IN 14KSTEPS RAM, MAX. I/O 1024, 0.2us/STEP |
| A2USHCPU-S1 | CPU, BUILT IN 30KSTEPS RAM, MAX. I/O 1024, 0.09us/STEP |
| A2ASCPU-S60 | CPU, BUILT IN 30KSTEPS RAM, MAX. I/O 1024, 0.15us/STEP |
| A1SCPUC24-R2 | CPU, BUILT IN 8KSTEPS RAM, MAX. I/O 256, RS232 PORT |
| A1SJHCPU | CPU, BUILT IN 8KSTEPS RAM, MAX. I/O 256, 5 I/O SLOTS |
| A1SJHCPU-S8 | CPU, BUILT IN 8KSTEPS RAM, MAX. I/O 256, 8 I/O SLOTS |
| BASE UNIT & EXTENSION UNITS | |
| A1S32B | BASE UNIT: CPU, 2 I/O & POWER SUPPLY SLOTS |
| A1S33B | BASE UNIT: CPU, 3 I/O & POWER SUPPLY SLOTS |
| A1S35B | BASE UNIT: CPU, 5 I/O & POWER SUPPLY SLOTS |
| A1S38B | BASE UNIT: CPU, 8 I/O & POWER SUPPLY SLOTS |
| A1S52B-S1 | EXTENSION UNIT : 2 I/O SLOTS |
| A1S55B-S1 | EXTENSION UNIT : 5 I/O SLOTS |
| A1S58B-S1 | EXTENSION UNIT : 8 I/O SLOTS |
| A1S65B-S1 | EXTENSION UNIT : 5 I/O, POWER SUPPLY SLOTS |
| A1S68B-S1 | EXTENSION UNIT : 8 I/O, POWER SUPPLY SLOTS |
| MEMORY CASSETTE | |
| A1SNMCA-8KP | MEMORY CASSETTE : 8K STEP EPROM 860 |
| A1SNMCA-2KE | MEMORY CASSETTE : 2K STEP EEPROM |
| A1SNMCA-8KE | MEMORY CASSETTE : 8K STEP EEPROM |
| A2SMCA-14KP | MEMORY CASSETTE : 14K STEP EPROM |
| A2SNMCA-30KE | MEMORY CASSETTE : 30K STEP EERPOM |
| A2SMCA-30KP | MEMORY CASSETTE : 30K STEP EPROM |
| A2SMCA-60KE | MEMORY CASSETTE : 60K STEP EEPROM |
| POWER SUPPLY | |
| A1S61PN | INPUT : AC 100 - 240V AC OUTPUT : DC 5V 8A |
| A1S62PN | INPUT : AC 100 - 220V AC OUTPUT : DC 5V 5A, DC 24V 0.8A 1,790 |
| A1S63P | INPUT : DC 24V OUTPUT : DC 5V 8A |
| BLANK AND DUMMY I/O MODULES | |
| A1SG60 | BLANK COVER |
| A1SG62 | DUMMY I/O MODULE, 16/32/64 SELECTABLE |
| INPUT UNIT | |
| A1SX10 | 16 PT. AC 100V |
| A1SX20 | 16 PT. AC 200V |
| A1SX30 | A1SX30 16 PT. AC 24V OR DC 24V 1,520 |
| A1SX40 | A1SX40 16 PT. DC 12/24V , SINK INPUT |
| A1SX40-S1 | A1SX40-S1 16 PT. DC 24V , SINK INPUT, FAST RESPONSE |
| A1SX40-S2 | A1SX40-S2 16 PT. DC 24V , SINK INPUT |
| A1SX41 32 PT. DC 12/24V | 32 PT. DC 12/24V , SINK INPUT |
| A1SX41-S1 | 32 PT. DC 24V , SINK INPUT, FAST RESPONSE |
| A1SX41-S2 | 32 PT. DC 24V , SINK INPUT |
| A1SX42 64 | PT. DC 12/24V , SINK INPUT |
| A1SX42-S1 | 64 PT. DC 24V , SINK INPUT, FAST RESPONSE |
| A1SX42-S2 | A1SX42-S2 64 PT. DC 24V , SINK INPUT |
| A1S42X 64 | PT. DYNAMIC INPUT |
| A1SX71 | PT. DC 5/12V ,SINK/SOURCE INPUT |
| A1SX80 | PT. DC 12/24V, SINK/SOURCE INPUT |
| A1SX80-S1 | 16 PT. DC 24V , SINK/SOURCE IN (HIGH SPEED) |
| A1SX80-S2 | 16 PT. DC 24V , SINK/SOURCE INPUT |
| A1SX81 | 32 PT. DC 12/24V , SINK/SOURCE INPUT |
| A1SX81-S2 | 32 PT. DC 24V, SINK/SOURCE INPUT |
| A1SX10EU | 16 PTS. AC 100V, EN/IEC STANDARD |
| A1SX20EU | 16 PTS. AC 200V, EN/IEC STANDARD |
| OUTPUT UNIT | |
| A1SY10 | 16 PT. AC 240V/DC 24V , 2A, RELAY |
| A1SY18A | 8 PT. AC 240V/DC 24V 2A, RELAY , INDEPENDENT COMMON |
| A1SY22 | 16 PT. AC 240V 0.6A, TRIAC/SSR |
| A1SY28A | 8 PT. AC 24V 1A, TRIAC/SSR, INDEPENDENT COMMON |
| A1SY40 | 16 PT. DC 12/24V 0.1A, TRANSISTOR SINK |
| A1SY41 | 32 PT. DC 12/24V 0.1A, TRANSISTOR SINK |
| A1SY42 | 64 PT. DC 12/24V 0.1A, TRANSISTOR SINK |
| A1SY50 | 16 PT. DC 12/24V 0.5A, TRANSISTOR SINK |
| A1SY60 | 16 PT. DC 24V 2A, TRANSISTOR SINK |
| A1SY68A | 8 PT. DC 5/12/24/48V 2A, TRANSISTOR SINK/SOURCE |
| A1SY71 | 32 PT. DC 5/12V 16mA, TRANSISTOR SINK |
| A1SY80 | 16 PT. DC 12/24V 16mA, TRANSISTOR SOURCE |
| A1SY81 | 32 PT. DC 12/24V 0.1A, TRANSISTOR SOURCE |
| A1SY10EU | 16 PT. AC 240V/DC 24V 2A, RELAY , EN/IEC STANDARD |
| A1SY14EU | 12 PT. AC 240V/DC 24V 2A, RELAY , EN/IEC STANDARD |
| A1SY18AEU | 8 PT. AC 240VDC 24V 2A, RELAY , EN/IEC STANDARD |
| A1SY28EU | AC 240V 1A, TRIAC/SSR, EN/IEC STANDARD |
| A1SH42 DC | DC 12/24V : 32 PT. SINK INPUT 32 PT. SINK TRANSISTOR OUTPUT |
| A1SX48Y18 | 8 PT. DC 12/24V SINK INPUT 8 PT. RELAY OUTPUT |
| A1SX48Y58 | 8 PT. DC 12/24V SINK INPUT 8 PT. SINK TRANSISTOR OUTPUT |
| ANALOG UNIT | |
| A1S63ADA | A/D, D/A CONVERTER : 2 INPUT/1 OUTPUT, 4-20mA, OR -10V-+10V |
| A1S66ADA | A/D, D/A CONVERTER : 4 INPUT/2 OUTPUT, 4-20mA, OR -10V-+10V |
| A1S64AD | A/D CONVERTER : 4 CH., 4-20mA, OR -10V-+10V |
| A1S68AD | A/D CONVERTER : 8 CH., 0-20mA, OR -10V-+10V |
| A1S62DA | D/A CONVERTER : 2 CH., 4-20mA, OR -10V-+10V |
| A1S68DAI | D/A CONVERTER UNIT : 8 CH., 4-20mA |
| A1S68DA | V D/A CONVERTER UNIT : 8 CH., -10V-+10V |
| A1ST60 | 8 ANALOG TIMERS |
| TEMPERATURE CONTROL UNIT | |
| A1S68TD | THERMOCOUPLE INPUT : 8 CH., B, R, S, E, J, K TYPE |
| A1S62RD3N | TEMPERATURE SENSOR : PT-100, 3 WIRES |
| A1S62RD4N | TEMPERATURE SENSOR : PT-100, 4 WIRES |
| A1S64TCTT-S1 | THERMOCOUPLE R,K,J,T,I/P,TRANSISTOR O/P, 4 CHANNEL |
| A1S64TCTTBW-S1 | 3-WIRE PT-100 I/P, TRANSISTOR O/P, 4 CHANNELS |
| A1S64TCRT-S1 | THERMOCOUPLE R,K,J,T,I/P,TRANSISTOR O/P, 4 CHANNEL |
| A1S64TCRTBW-S1 | 3-WIRE PT-100 I/P, TRANSISTOR O/P, 4 CHANNELS |
| POSITIONING UNIT | |
| A1SD70 | AXES, VOLTAGE OUTPUT |
| A1SD71-S2 | 2 AXIS, PULSE TRAIN, OUTPUT, SPEED CONTROL FUNCTION |
| A1SD71-S6 | 2 AXIS, PULSE TRAIN OUTPUT |
| A1SD71-S7 | 2 AXIS, PULSE TRAIN OUTPUT, MANUAL PULSAR INPUT |
| A1SD75P1-S3 | 1 AXES, PULSE TRAIN OUTPUT |
| A1SD75P2-S3 | 2 AXIS, PULSE TRAIN OUTPUT |
| A1SD75P3-S3 | 3 AXIS, PULSE TRAIN OUTPUT |
| A1SD75-C01H | CONNECTION CABLE BETWEEN A1SD75 & AD75TU |
| A1SP60 | PULSE CATCH MODULE |
| A1SD75M1 | SSC NET, 1ASIS |
| A1SD75M2 | SSC NET, 2ASIS |
| A1SD75M3 | SSC NET, 3ASIS |
| AD75TU AD75 | AD75 TEACHING PANEL |
| OTHER SPECIAL FUNCTION UNIT | |
| A1SD61 | HIGH SPEED COUNTER, 1 CH., 50KPPS |
| A1SD62 | HIGH SPEED COUNTER, 2 CH., 100KPPS, SINK |
| A1SD62E | HIGH SPEED COUNTER, 2 CH., 100KPPS, SOURCE |
| A1SD62D | HIGH SPEED COUNTER, 2 CH., 200KPPS, SINK |
| A1SI61 | 16 PT. INTERRUPT MODULE |
| DATA LINK UNIT | |
| A1SJ71LP21 | MELSECNET/10, OPTICAL FIBER SI-200/250 |
| A1SJ71BR11 | MELSECNET/10, COAXIAL CABLE |
| A1SJ71AP21 | MELSECNET/II, MASTER/LOCAL, FIBER OPTIC SI-200/250 |
| A1SJ71AR21 | MELSECNET/II, MASTER/LOCAL, COAXIAL CABLE |
| A1SJ71AT21B | MELSECNET/B, MASTER/LOCAL |
| A1SJ72T25B | MELSECNET/B, REMOTE STATION |
| A1SJ71E71N-B2 | ETHERNET INTERFACE UNIT, 10BASE2 |
| A1SJ71E71N-B5T | ETHERNET INTERFACE UNIT, 10BASE-T/10BASE5 |
| A1SJ71PT32-S3 | MELSECNET/MINI-S3 MASTER, OPTICAL/TWISTED PAIR |
| A1SJ71T32-S3 | MELSECNET/MINI-S3 MASTER, TWISTED PAI |
| A1SJ71UC24-R2 | RS232C INTERFACE |
| A1SJ71UC24-R4 | RS422/485 INTERFACE |
| A1SJ71UC24-PRF | RS232C INTERFACE & PRINTER FUNCTION |
| A1SJ71UC24-R2-S2 | MODUS, RS232C INTERFACE |
| A1SJ71UC24-R4-S2 | MODUS, RS422/485 INTERFACE |
| A1SD51S RS232C | RS232C 2 CH., RS422/484 1 CH. |
| A1SJ71LP21GE | MELSECNET/10, OPTICAL FIBER GI-62.5/125 |
| A1SJ71PB96F | PROFIBUS-FMS INTERFACE MODULE |
| A1SJ71PB92D | PROFIBUS-DP INTERFACE MODULE |
| MELESEC I/O LINK UNIT | |
| A1SJ51T64 | MELSECNET I/O LINK MASTER, 64 REMOTE I/O CONTROL |
| AJ55TB3-4D | REMOTE INPUT, 4 PTS, DC24V |
| AJ55TB3-8D | REMOTE INPUT, 8 PTS, DC24V |
| AJ55TB3-16D | REMOTE INPUT, 16 PTS, DC24V |
| AJ55TB2-4T | REMOTE OUTPUT, 4 PTS, TRANSISTOR(SINK), DC24V 0.5A/PT. |
| AJ55TB2-8T | REMOTE OUTPUT, 8 PTS, TRANSISTOR(SINK), DC24V 0.5A/PT. |
| AJ55TB2-16T | REMOTE OUTPUT, 16 PTS, TRANSISTOR(SINK), DC24V 0.5A/PT. |
| AJ55TB2-4R | REMOTE OUTPUT, 4 PTS, RELAY , AC240V 2A/PT |
| AJ55TB2-8R | REMOTE OUTPUT, 8 PTS, RELAY , AC240V 2A/PT. |
| AJ55TB2-16R | REMOTE OUTPUT, 16 PTS, RELAY , AC240V 2A/PT. |
| AJ55TB32-4DT | INPUT 2 PTS, DC24V / OUTPUT 2 PTS, TRAN.(SINK) DC24V 0.5A/PT |
| AJ55TB32-8DT | INPUT 4 PTS, DC24V / OUTPUT 4 PTS, TRAN.(SINK) DC24V 0.5A/PT. |
| AJ55TB32-16DT | INPUT 8 PTS, DC24V / OUTPUT 8 PTS, TRAN.(SINK) DC24V 0.5A/PT. |
| AJ55TB32-4DR | INPUT 2 PTS, DC24V / OUTPUT 2 PTS, RELAY AC240V 2A/PT |
| AJ55TB32-8DR | INPUT 4 PTS, DC24V / OUTPUT 4 PTS, RELAY AC240V 2A/PT. |
| AJ55TB32-16DR | INPUT 8 PTS, DC24V / OUTPUT 8 PTS, RELAY AC240V 2A/PT |
| DEVELOPMENT TOOLS | |
| A6WA-28P | READ/WRITE ADAPTER FOR A1SMCA-8KP |
| A2SWA-28P | READ/WRITE ADAPTER FOR A2SMCA-14KP |
| A7PUS | HANDY PROGRAMMER FOR AnS |
| AC30R4-PUS | A7PU CABLE, 3 M LONG |
| A6BAT | BATTERY FOR MEMORY BACKUP |
| EXTENSION CABLE | |
| A1SC01B | 55 mm EXTENSION CABLE |
| A1SC03B | 300 mm EXTENSION CABLE |
| A1SC60B | 6 M EXTENSION CABLE |
| A1SC05NB | 450 mm CABLE CONNECTS TO AnN EXTENSION BASE & GOT |
| A1SC07NB | 700 mm CABLE CONNECTS TO AnN EXTENSION BASE & GOT |
| A1SC30NB | 3 M CABLE CONNECTS TO AnN EXTENSION BASE & GOT |
| A1SC50NB | 5 M CABLE CONNECTS TO AnN EXTENSION BASE & GOT |
| TERMINAL UNIT | |
| A6TE2-16SRN | 16 PTS, RELAY OUTPUT UNIT, APPLICABLE TO A1SY41/42 |
| AC06TE | 0.6 M CABLE FOR A6TE2-16SR |
| AC10TE | 1 M CABLE FOR A6TE2-16SR |
| AC30TE | 3 M CABLE FOR A6TE2-16SR |
| AC50TE | 5 M CABLE FOR A6TE2-16SR |
| AC100TE | 10 M CABLE FOR A6TE2-16SR |
| TERMINAL ADAPTER | |
| A1STA32 | AWG 20 (0.5mm2), FOR A1SX41/42-S2/71, A1SY41/71 |
| A1STA32-3 | AWG 22 (0.3mm2), FOR A1SX41/42-S2/71, A1SY41/71 |
| A1STA32-7 | 32 PTS, AWG 18 (0.7mm2), FOR A1SX41/42-S2/71, A1SY41/71 |
| CONNECTOR/TERMINAL CONVERTER | |
| A6TBXY36 | 36 PTS, SINK, APPLICABLE TO A1SX41/42 & A1SY41/42 |
| A6TBXY54 | 54 PTS, SINK, APPLICABLE TO A1SX41/42 & A1SY41/42 |
| A6TBX70 | 70 PTS, SINK INPUT, APPLICABLE TO A1SX41/42 |
| A6TBX36-E | 36 PTS, SOURCE INPUT, APPLICABLE TO A1SX81 |
| A6TBY36-E | 36 PTS, SOURCE OUTPUT, APPLICABLE TO A1SY81 |
| A6TBX54-E | 64 PTS, SOURCE INPUT, APPLICABLE TO A1SX81 |
| A6TBY54-E | 54 PTS, SOURCE OUTPUT, APPLICABLE TO A1SY81 |
| A6TBX70-E | 70 PTS, SOURCE INPUT, APPLICABLE TO A1SX81 |
| AC05TB | 0.5 M CABLE, SINK TYPE, APPLICABLE TO A6TB( ) |
| AC10TB | 1 M CABLE, SINK TYPE, APPLICABLE TO A6TB( ) |
| AC20TB | 2 M CABLE, SINK TYPE, APPLICABLE TO A6TB( ) |
| AC30TB | 3 M CABLE, SINK TYPE, APPLICABLE TO A6TB( ) |
| AC50TB | 5 M CABLE, SINK TYPE, APPLICABLE TO A6TB( ) |
| CPU | |
| A3ACPU | (30K+30K)STEPS, 2048 I/O, HIGH FUNCTION (0.15 uS/STEP) |
| A3ACPUP21 | A3ACPU WITH MELSECNET II OPTICAL DATA LINK |
| A3ACPUR21 | A3ACPU WITH MELSECNET II COAXIAL DA TA LINK |
| A2ACPU-S1 | 14KSTEPS, 1024 I/O, HIGH FUNCTION |
| A2ACPUP21-S1 | A2ACPU-S1 WITH MELSECNET II OPTICAL DA TA LINK |
| A2ACPUR21-S1 | WITH MELSECNET II COAXIAL DATA LINK |
| A2ACPU | 14KSTEPS, 512 I/O, HIGH FUNCTION |
| A2ACPUP21 | A2ACPU WITH MELSECNET II OPTICAL DATA LINK |
| A2ACPUR21 | A2ACPU WITH MELSECNET II COAXIAL DA TA LINK |
| A3NCPU | 30K+30K)STEPS, 2048 I/O |
| A3NCPUP21 | A3NCPU WITH MELSECNET II OPTICAL DATA LINK |
| A3NCPUR21 | A3NCPU WITH MELSECNET II COAXIAL DATA LINK |
| A2NCPU-S1 | A2NCPU-S1 14KSTEPS, 1024 I/O |
| A2NCPUP21 | A2NCPU-S1 WITH MELSECNET II OPTICAL DA TA LINK |
| A2NCPUR21-S1 | A2NCPU-S1 WITH MELSECNET II COAXIAL DATA LINK |
| A2NCPU | 14KSTEPS, 512 I/O |
| A2NCPUP21 | A2NCPU WITH MELSECNET II OPTICAL DATA LINK |
| A2NCPUR21 | A2NCPU WITH MELSECNET II COAXIAL DATA LINK |
| A1NCPU | 6KSTEPS, 256 I/O |
| A1NCPUP21 | A1NCPU WITH MELSECNET II OPTICAL DATA LINK |
| A1NCPUR21 | A1NCPU WITH MELSECNET II COAXIAL DA TA LINK |
| A0J2HCPU | 8K STEPS, 480 I/O, 1.25uS/STEP |
| BASE UNIT | |
| A32B | BASE UNIT WITH : CPU, 2 I/O & POWER SUPPLY SLOTS |
| A35B | BASE UNIT WITH : CPU, 5 I/O & POWER SUPPLY SLOTS |
| A38B | BASE UNIT WITH : CPU, 8 I/O & POWER SUPPLY SLOTS |
| A52B | EXTENSION UNIT WITH : 2 I/O SLOTS |
| A55B | EXTENSION UNIT WITH : 5 I/O SLOTS |
| A58B | EXTENSION UNIT WITH : 8 I/O SLOTS |
| A62B | EXTENSION UNIT WITH : 2 I/O, POWER SUPPLY SLOTS |
| A65B | EXTENSION UNIT WITH : 5 I/O, POWER SUPPLY SLOTS |
| A68B | EXTENSION UNIT WITH : 8 I/O, POWER SUPPLY SLOTS |
| POWER SUPPLY | |
| A61P | INPUT : AC 110/240V OUTPUT : DC 5V 8A |
| A62P | INPUT : AC 110/240V OUTPUT : DC 5V 5A, DC 24V 0.8A |
| A63P | INPUT : DC 24V OUTPUT : DC 5V 8A |
| A65P | INPUT : AC 110/240V OUTPUT : DC 5V 2A, DC 24V 1.5A |
| A66P | INPUT : AC 110/240V OUTPUT : DC 24V 1.2A |
| A68P | INPUT : AC 110/240V OUTPUT : DC 1.5V |
| MEMORY CASSETTE | |
| A3NMCA-0 | MEMORY CASSETTE : NO MEMORY , USE 4K RAM IC |
| A3NMCA-2 | MEMORY CASSETTE : 16K BYTE MEMORY RAM |
| A3NMCA-4 | MEMORY CASSETTE : 32K BYTE MEMORY RAM |
| A3NMCA-8 | MEMORY CASSETTE : 64K BYTE MEMOR RAM |
| A3NMCA-16 | MEMORY CASSETTE : 128K BYTE MEMORY RAM |
| A3NMCA-24 | MEMORY CASSETTE : 192K BYTE MEMORY RAM |
| A3NMCA-40 | MEMORY CASSETTE : 320K BYTE MEMORY RAM |
| A3NMCA-56 | MEMORY CASSETTE : 448K BYTE MEMORY RAM |
| MEMORY | |
| 4KRAM | 4K STEP MEMORY (A1N, A3NMCA-0) |
| 16KRAM | 16K STEP RAM |
| 4KROM | STEP EP-ROM (A1N, A3NMCA-0) |
| 8KROM | 8K STEP EP-ROM |
| 16KROM | 16K STEP EP-ROM |
| 16KHROM | 16K STEP EP-ROM FOR AD57(S1/S2), AD58 |
| 16KQROM | EP-ROM MEMORY+B213 |
| 4KEROM | EP-ROM MEMORY |
| 64KWROM | 56K BYTE MEMORY FOR AD51H, AD57G |
| 128KWROM | 128K BYTE MEMORY FOR AD51H, AD57G |
| 256KWROM | 256K BYTE MEMORY FOR AD51H, AD57G |
| BYPASS SWITCH | |
| A6BSW-P-S3 | BYPASS SWITCH |
| A6BSW-P-S4 | BYPASS SWITCH |
| A6BSW-P-S5 | BYPASS SWITCH |
| INPUT UNIT | |
| AX10 16 | 16 PTS. AC 100V , 10mA |
| AX11 32 | 32 PTS. AC 100V , 10mA |
| AX20 16 | 16 PT. AC 200V , 10mA |
| AX21 32 | 32 PT. AC 200V 10mA |
| AX40 16 | 16 PT. DC 12/24V , SINK INPUT (4/10mA) |
| AX41 32 | 32 PT. DC 12/24V , SINK INPUT (4/10mA) |
| AX41-S1 | 32 PT. DC 12/24V , SINK INPUT (4/10mA), FAST RESPONSE |
| AX42 64 | 64 PT. DC 12/24V , SINK INPUT (3/7mA) |
| AX42-S1 | 64 PT. DC 12/24V , SINK INPUT (3/7mA), FAST RESPONSE |
| AX50-S1 | 16 PT. DC 48V SINK/SOURCE (4mA) |
| AX60-S1 | 16 PT. DC 100/110/125V , SINK/SOURCE (2mA) |
| AX70 | 16 PT. DC 5/12/24V , SINK/SOURCE INPUT (2mA) |
| AX71 | 32 PT. DC 5/12/24V , SINK/SOURCE INPUT (3.5/2/4.5mA) |
| AX80 | 16 PT. DC 12/24V , SOURCE INPUT (4/10mA) |
| AX80E | 16 PT. DC 12/24V , SOURCE INPUT (4/10mA), FAST RESPONSE |
| AX81 | 32 PT. DC 12/24V , SOURCE INPUT (4/10mA) |
| AX82 | 64 PT. DC 12/24V , SOURCE INPUT (8/7mA) |
| OUTPUT UNIT | |
| AY10 | 16 PT. RELAY OUTPUT, 2A |
| AY10A | 16 PT. RELAY OUTPUT, 2A (INDEPENDENT COMMONS) |
| AY11 | 16 PT. RELAY OUTPUT, 2A |
| AY11A | 16 PT. RELAY OUTPUT2A (INDEPENDENT COMMONS) |
| AY11E | 16 PT. RELAY OUTPUT 2A (FUSED COMMON) |
| AY13 | 32 PT. RELAY OUTPUT 2A |
| AY13E | 32 PT. RELAY OUTPUT 2A (FUSED COMMON) |
| AY22 | 16 PT. TRIAC OUTPUT 2A |
| AY23 | 32 PT. TRIAC OUTPUT 0.6A |
| AY40 | 16 PT. DC 12/24V TRANSISTOR SINK OUTPUT 0.1A |
| AY40A | 16 PT. DC 12/24V TRANSISTOR SINK OUTPUT 0.3A ( INDEPENDENT) |
| AY40P | 16 PT. DC 12/24V TRANSISTOR SINK 0.1A (SHORT CCT. PROTECTION) |
| AY41 | 32 PT. DC 12/24V TRANSISTOR SINK 0.1A |
| AY41P | 16 PT. DC 12/24V TRANSISTOR SINK 0.1A (SHORT CCT. PROTECTION) |
| AY42 | PT. DC 12/24V TRANSISTOR SINK 0.1A |
| AY42-S1 | 64 PT. DC 12/24V TRANSISTOR SINK 0.1A (HIGH SPEED) |
| AY42-S3 | 64 PT. DC 12/24V TRANSISTOR SINK 0.1A (FUSED) |
| AY50 | DC 12/24V TRANSISTOR SINK 0.5A |
| AY51 | 32 PT. DC 12/24V TRANSISTOR SINK 0.5A |
| AY51-S1 | 32 PT., DC 12/24V TRANSISTOR SINK 0.3A |
| AY60 | 16 PT. DC 12/24/48V TRANSISTOR SOURCE 2A |
| AY60E | 16 PT. DC 12/24/48V TRANSISTOR SOURCE 0.5A |
| AY60S | 16 PT. DC 24/48V TRANSISTOR SINK FOR TTL & CMOS, 2A |
| AY70 | 16 PT. DC5/12V TRANSISTOR SINK FOR TTL & CMOS 16mA |
| AY71 | 32 PT. DC5/12V TRANSISTOR SINK FOR TTL & CMOS 16mA |
| AY72 | 64 PT. DC 5/12V TRANSISTOR SINK FOR TTL & CMOS, 16mA |
| AY80 | 16 PT. DC 12/24V TRANSISTOR SOURCE OUTPUT, 0.5A |
| AY81 | 32 PT. DC 12/24V TRANSISTOR SOURCE, 0.5A |
| AY81EP | 32 PT. DC 12/24V TRANSISTOR SOURCE, 0.8A |
| WITH SHORT CIRCUIT PROTECTION | |
| AY82EP | 64 PT. DC 12/24V TRANSISTOR SOURCE, 0.1A |
| WITH SHORT CIRCUIT PROTECTION | |
| A42XY | 64 PT. INPUT, 64 PT. SINK OUTPUT, DC 12/24V , 55/180mA |
| AH42 | 2 PT. INPUT, 32 PT. SINK OUTPUT, DC 12/24V |
| ANALOG UNIT | |
| A68AD | A/D CONVERTER : 8 CH., 4-20mA, OR -10V-+10V |
| A68ADN | A/D CONVERTER : 8 CH., 0-20mA OR -10V-+10V (HIGH RESOLUTION) |
| A616AD | A/D CONVERTER : 16 CH., 4-20mA, OR -10V-+10V |
| A60MX | MULTIPLEXER UNIT : 16 CHANNELS, NON-ISOLA |
| A60MXR | MULTIPLEXER UNIT : 16 CHANNELS, ISOLATED MERCURY RELAY |
| A616TD | THERMOCOUPLER CONVERTER UNIT : 16 CHANNELS |
| A60MXT | THERMOCOUPLER MULTIPLEXER UNIT : 16 CHNNELS |
| A68DA | V D/A CONVERTER UNIT : 8 CHANNELS, VOLTAGE OUTPUT |
| A68DAI-S1 | D/A CONVERTER UNIT : 8 CHANNELS |
| A62DA D/A | D/A CONVERTER UNIT : 2 CH., 4-20mA OR -10V-+10V |
| A62DA-S1 | D/A CONVERTER UNIT : 2 CH., 4-20mA, 0-20mA OR -10V-+10V |
| A616DA | V D/A CONVERTER UNIT : 16 CHANNELS, VOLTAGE OUTPUT |
| A616DAI | D/A CONVERTER UNIT : 16 CHANNELS, CURRENT OUTPUT |
| AC12MX | CONNECTION CABLE FOR MULTIPLEXER UNIT (1.2m LONG) |
| A68RD3N | THERMOCOUPLE INPUT UNIT : PT100, 3 WIRES |
| A68RD4N | THERMOCOUPLE INPUT UNIT : PT100, 4 WIRES |
| POSITIONING UNIT | |
| AD61 | HIGH SPEED COUNTER : 2 CH., 50KPPS(1/2 PHASE) |
| AD61S1 | HIGH SPEED COUNTER : 2 CH. , 10KPPS/1 PHASE, 7KPPS/2 PHASES |
| AD71-S2 | POSITIONING CONTROL : 2 AXES, PULSE TRAIN OUTPUT |
| AD71TU | TEACHING UNIT FOR AD71/72 |
| AD72 | POSITIONING CONTROL : 2 AXES, ANALOG OUTPUT |
| AD75P1-S3 | PULSE TRAIN O/P, 1 AXIS |
| AD75P2-S3 | PULSE TRAIN O/P, 2 AXES |
| AD75P3-S3 | PULSE TRAIN O/P, 3 AXES |
| INTELLIGENT UNIT | |
| AD51H-S3 | AD51H-BASIC, 2 X RS422, 1 X RS232, 1 X PARALLEL |
| AJ71UC24 | COMPUTER LINK UNIT |
| AJ71UC24-S2 | RS232/RS422/485 MODBUS PROTOCOL MODULE |
| AJ71C22-S1 | MULTIDROP LINK UNIT |
| DATA LINK UNIT | |
| AJ71E71N-B5T | ETHERNET INTERFACE UNIT, 10BASE-T/10BASE5 |
| AJ71E71N-B2 | ETHERNET INTERFACE UNIT, 10BASE2 |
| AJ71AP21 | MELSECNET MASTER/LOCAL, OPTICAL LINK |
| AJ71AR21 | MELSECNET MASTER/LOCAL, COAXIAL LINK |
| AJ72P25 | MELSECNET REMOTE I/O CONTROLLER, OPTICAL LINK |
| AJ72R25 | MELSECNET REMOTE I/O CONTROLLER, COAXIAL LINK |
| AJ71AT21B | MELSECNET/B MASTER/LOCAL |
| AJ72T25B | MELSECNET/B REMOTE STATION |
| A7BDE-J71AP21 | MELSECNET BOARD FOR IBM COMPA TIBLE PC, OPTICAL LINK |
| A7BDE-J71AR21 | MELSECNET BOARD FOR IBM COMPATIBLE PC, COAXIAL LINK |
| AJ71PT32-S3 | MELSECNET/MINI MASTER UNIT |
| AJ71LP21 | MELSECNET/10 MASTER/LOCAL, SI-200/250 OPTICAL LINK |
| AJ71LP21G | MELSECNET/10 MASTER/LOCAL, GI-50/125 TYPE OPTICAL LINK |
| AJ71LP21GE | MELSECNET/10 MASTER/LOCAL, GI-62.5/125 TYPE OPTICAL LINK |
| AJ71BR11 | MELSECNET/10 MASTER/LOCAL, COAXIAL |
| A6BR10 | MELSECNET/10 COAXIAL CABLE REPEATER |
| A6BR10-DC | MELSECNET/10 COAXIAL CABLE REPEATER, DC24V P/S |
| AJ61BT11 | MASTER/LOCAL MODULE FOR ACPU |
| OTHER SPECIAL FUNCTION UNIT | |
| AI61 | 16 PT. INTERRUPT MODULE |
| A11VC | VOICE OUTPUT MODULE |
| A6FD | ASCII CHARACTER DISPLAY UNIT |
| AS91 | SYSTEM MONITOR MODULE |
| AG60 | BLANK UNIT |
| AG62 | DUMMY UNIT : 16/32/48/64 POINT SELECTABLE |
| DEVELOPMENT TOOLS | |
| A7PU | PROGRAMMING PANEL FOR A-SERIES PLC |
| A8PUE | PROGRAMMING PANEL (SPECIALLY FOR AnA/AnU SERIES PLC) |
| AC20R4-A8PU | CONNECTION CABLE BETWEEN A8PU AND CPU, 2m LONG |
| AC300R4 RS422 | CABLE BETWEEN THE GPP AND CPU, 30m LONG |
| AC30R4 RS422 | CABLE BETWEEN THE GPP AND CPU, 3m LONG |
| AC30R2 RS232 | CABLE BETWEEN GPPAND SERIAL PRINTER, 3m LONG |
| A6SW16 | SIMULATION SWTICH : 16 INPUT POINT |
| A6SW32 | SIMULATION SWITCH : 32 INPUT POINT |
